直线轨迹机构的解析法设计
ANALYTIC DESIGN TO PATH GENERATOR FOR STRAIGHT LINE
-
摘要: 本文研究了用解析法设计实现直线轨迹的平面铰按机构的一种计算方法,并算出了实例的数字结果。从由所得数字结果得出的机构运动轨迹可见,这种设计方法有很高的精度。这种方法也可用于其他轨迹实现机构的设计,有较高的实用意义。Abstract: In this paper,research on the analytic design method to hinged planar mechanisms is reported.Synthesis of path generator for prescribed points lying in a straight line was studied and the numeral result of a correlative example calculated.The tracer generated from the numeral result coincided well with the given line.The calculation method offered in this paper can be further applied to other planar linkage design.
-
Keywords:
- Path generator /
- Complex number /
- multiloop mechanisms
-
